Main Features:
◆Separated structural design, easy to operate, according to the new national standard GBl9758-2005 technical requirements for development.
◆With built-in full-flow sampling techniques, application-specific measurement of motorcycle hard phases of acceleration, idle condition when the smoke.
◆High-brightness digital display, import key components assembled.
◆Using a special full-flow high-temperature sampling probe, sampling a stable, accurate and convenient.
◆Ji machine warm-up time 10 minutes, and automatic zero adjustment.
◆Linear automatic data processing, can be displayed opacity degrees N, light absorption coefficient K.
◆Fails automatically displays fault code.
◆With automatic clock display, built-in printer (RS-232 or analog interface network) for selection.
Main technical parameters:
Test Scope：No light transmission N: 0～100%
Light absorption coefficient K: 0～90.65 m-1
Shows the value error：≤ ± 2%
Stability：Automatic zero, volume moments drift ≤ ± 1% / 4h
Resolution：0.1%
Response Time：1S ± 0.1S
Output Mode：LED (4-bit) display can be attached to the printer 5 groups hard phases
of acceleration smoke, idle smoke, the light absorption coefficient of
the maximum and the average test time, date, etc., can be attached to
interface with the computer network
Environmental conditions：Temperature -5 ~ 50 ℃, relative humidity ≤ 90%
Power：AC100-240V 50/60Hz Power consumption 150VA
Dimensions：Control Box::：240mm (L) × 310mm (W) × 170mm (H)
Flue Box：350mm (L) × 260mm (W) × 170mm (H)
Weight：Control box: 4kg, flue box: 5kg
